Poliplex PE100 Pipe

Yes. POLlplex^® PE pipes contain either carbon black or chemical stabilisers to protect them from the effects of ultra violet radiation. Black poly pipes are suitable for long-term external exposure to sunlight. Coloured pipe may be stored for up to 2 years in direct sunlight. For long-term exposure in above ground applications, lplex recommends the use of white THERMAPIPE®.

Generally no. POLIplex® PE pipes are fully welded or mechanically restrained, however it may be necessary to provide thrust restraint where POLlplex® pipelines connect to rubber ring jointed pipelines or other non-restrained pipes or fittings. For more information, contact lplex Pipelines.

Polyethylene pipes require a different test procedure to PVC or Ductile Iron pipelines to compensate for the materials tendency to strain during pressure testing. If the correct test procedure is not used, the pipeline may appear to fail the test. Detailed information on the correct procedure is contained in Australian Standard AS/NZS 2033.

Yes. However PE pipes require rerating due to its elevated temperature and the stored energy contained in compressed air. Information is available in PIPA Industry Guideline POP002 "Polyethylene (PE) Pipes and Fittings for Compressed Air", which can be accessed at www.pipa.com.au

All temperature above 25°C, polyethylene pipes require pressure rerating - at very high temperatures as well as very low tempera­tures. The life of polyethylene pipes may be substantially reduced. For detailed information, refer to PIPA Industry Guideline POP013 "Temperature rerating of PE pipes", which can be accessed at www.pipa.com.au

Whilst polyethylene is a highly chemical resistant material, there are some chemicals which are unsuitable for carriage in HDPE pipes, or may reduce their service life. For detailed information on the interaction between polyethylene pipes and most chemicals, refer to the Iplex Chemical Resistance Tool

Yes. Welding by untrained operators is the most common cause of joint failure in polyethylene pipelines. Australian Standard AS/NZS 2033 stipulates that polyethylene welders must be trained and certified by a Registered Training Organisation and that welding procedures must be in accordance with PIPA Industry Guidelines POP00 1 "Electrofusion Jointing of PE pipe and fittings for pressure applications" and/or POP003 "Butt Fusion Jointing of PE pipes and fittings - recommended parameters". More information can be accessed at www.pipa.com.au

Fittings should be stored out of the direct sunlight and in their original boxes and sealed plastic bags until immediately before use. Ideally, couplings should be stored on their flat ends.

Contamination is the most prevalent cause of failure of electrofusion fittings Failure to preserve the manufacturer's packaging of fittings increases the risk of UV oxidisation or surface contamination possibly rendering the fitting useless or unsaleable.

lplex Pipelines stock cleaning wipes that are ideal for installation preparation Methylated spirits contain residual oils that will contami­nate the welding surface and should not be used.

Coiled pipe will become oval due to the stress induced during coiling and must be rerounded using the correct tools prior to welding. lplex stock a variety of rerounding equipment suitable for this purpose (Refer to page 100 for a list of available rerounding equipment).

SOR is the Standard Dimensional Ratio of the pipe outside diameter to wall thickness. PN ratings are the nominal pressure rating of the pipe, but only when it is carrying non-viscous fluids at 20°C. SOR is the preferred method for specifying the grade of pipe required.

There are many factors that may affect the life of polyethylene pipelines. They include temperature, fluid type, installation method, UV exposure and cyclic loading. When correctly installed in underground applications, POLlplex® pipes conveying water will have an anticipated service of in excess of 100 years.
